Highlights

Heavy-duty Construction: The machine main frame is robustly constructed, welded, sand blasted, and powder coated for durability.

First Work Station: Features a wide abrasive belt head for sanding down larger burrs and surface finishing, including No.4 finishing. Equipped with servo lifting for precise height (thickness) adjustment.

Planetary Abrasive Barrel Station: Consists of six abrasive barrels covering the entire working width, with each pair rotating in opposite directions for consistent and even pressure across edges, corners, and holes.

Full Working Width Vacuum Conveyor: Facilitates processing of small workpieces up to 60x60mm (solid surface area).

Balanced Rollers: Ensures high rotational speed and precision with properly balanced essential rollers.

Planetary Abrasive Barrel Operation: Primarily targets edges, corners, and holes, with minimal touch on flat surfaces, making it suitable for parts with vinyl film.

Profile Part Processing: Capable of handling minor profiled parts depending on shape, form, height, and size.

Durable Consumables: Long life span reduces the need for frequent replacements.

User-friendly Interface: Features an easy-to-use touch screen interface with built-in LED lighting.

Specifications

Maximum Working Width: 1000mm

Consumables: Wide abrasive belt, abrasive barrel

Working Thickness Range: 0-50mm

Conveyor Speed: 0.8-5m/min

Weight: 4000KGS

Applications

Designed for deburring, edge rounding, and surface finishing of parts from laser cutting, stamping, fine blanking, punching, shearing, and water jet cutting machines with sharp edges and minor-moderate burrs.

The SGP1000, with its two work stations, is ideal for parts requiring surface sanding, vertical burr removal, and surface finishing. The planetary abrasive barrel station further deburrs and rounds edges.

This machine ensures safe operation with minimal dust exposure, making it suitable for clean and efficient workflows.

Good Fit Materials

Suitable for steel, stainless steel, aluminum, copper, various alloys, and more.

Effective on parts with vinyl films and those requiring heavily rounded edges before the coating process.

Additional Machine Models (Modular Design)

SGP1000 Single Barrel: Ideal for softer metals like copper and aluminum, and parts with minor burrs.

SGP1000 Dual Barrel: Best for parts with heavier burrs or high-hardness metal alloys.

SGP1000 Full Configuration: Combines wide abrasive belt, planetary barrel, and polishing barrel stations for comprehensive finishing.

Optional Features: Magnetic conveyor table for ferrous metal workpieces
